16 AWG, 3 Conductor, Communication and Control Cable, Unshielded, 500ft or 1000ft Spool
General Cable C2406A, UL 2464, UL 2587, NEC Type CL3, NEC/CEC Type CMG UL/CSA
Color:
Gray
Applications:
Public address systems, Intercoms, Internal telephones, Remote control circuits, Suitable for EIA RS-232 applications, Suggested voltage rating: 300 volts
Compliances:
- NEC Article 725 Type CL3 (UL: 75°C)
- NEC Article 800 Type CM (UL: 75°C)
- UL Style 2464 (UL: 80°C, 300 V)
- UL Style 2587 (UL: 90°C, 600 V)
- CSA CMG (CSA: 60°C)
- RoHS Compliant Directive 2011/65/EU
- Designed to meet UL 70,000 BTU Vertical Tray Flame Test
- Passes CSA CMG Flame Test
- CE: Low Voltage Directive (LVD) 2006/95/EC
Conductor:
Fully annealed, solid or stranded tinned copper per
Insulation:
Color Coded, Polyvinyl Chloride (PVC)
Jacket:
PVC, gray
-20°C to +90°C
Specifications*:
Size: 16 AWG
Number of Conductors: 3
Conductor Stranding: 19/.0117
Nominal Insulation Thickness: 0.021 inches
Nominal Jacket Thickness: 0.032 inches
Outside Diameter: 0.283 inches
Nominal C-C Cap. pF/ft: 30.5
